一、30T-2 PUMP Rated bhp at 500 rpm 30HP(22.4KW) Stroke 2″ (50.8 mm ) Maximum working pressure “L” MODEL 2000PSI （13,788KPA）“H” MODEL 5000PSI ( 34,470KPA ) Max. plunger 2-1/4″（57.2mm） Key 1/2″ x 1/4″ (12.7mm x 6.4mm) Weight 640kg 二、30T-2 Performance Data 三、National PUMP
一、60T-3 PUMP Rated bhp at 500 rpm 60HP(44.74KW) Stroke 3″ (76.2mm ) Maximum working pressure “L” MODEL 1500PSI （10,342KPA）“M” MODEL 3200PSI ( 22,063KPA )“H” MODEL 5000PSI ( 34,474KPA ) Max. plunger 3″ (76.2mm ) Key 5/8″ x 5/16″ (15.9mm x 7.9mm) Weight 1145kg 二、60T-3 Performance Data 三、National PUMP
一、80T-3 PUMP Rated bhp at 500 rpm 80HP(59.65KW) Stroke 3″ (76.2 mm ) Maximum working pressure “L” MODEL 2016PSI （13,901KPA）“M” MODEL 4267PSI ( 29,420KPA )“H” MODEL 5161PSI ( 35,598KPA ) Max. plunger 3-3/8″（85.7mm） Key 5/8″ x 5/16″ (15.9mm x 7.9mm) Weight 1195kg 二、80T-3 Performance Data 三、National PUMP
一、100T-4 PUMP Rated bhp at 450 rpm 100HP(75KW) Stroke 4″ (101.6 mm ) Maximum working pressure “L” MODEL 1659PSI （11,436KPA）“M” MODEL 3180PSI ( 21,925KPA )“H” MODEL 5000PSI ( 34,474KPA ) Max. plunger 3-3/8 ″（85.7 mm） Key 5/8″ x 5/16″ (15.9mm x 7.9mm) Max. plunger 2300kg 二、100T-4 Performance Data 三、National PUMP
一、130T-4 PUMP Rated bhp at 450 rpm 130HP(97KW) Stroke 4″ (101.6 mm ) Maximum working pressure “L” MODEL 1750PSI （12070KPA）“M” MODEL 3111PSI ( 21458KPA )“H” MODEL 5000PSI ( 34474KPA ) Max. plunger 3-5/8″（92.1mm） Key 5/8″ x 5/16″ (15.9mm x 7.9mm ) Weight 2360kg 二、130T-4 Performance Data 三、National PUMP
一、165T-5 PUMP Rated bhp at 400 rpm 165HP(123KW) Stroke 5″ (127 mm ) Maximum working pressure “L” MODEL 1650PSI （11376KPA）“M” MODEL 3120PSI ( 21512KPA )“H” MODEL 5000PSI ( 34474KPA ) Max. plunger 4 ″（102mm） Key 1″ x 1/2″ (25.4mm x 12.7mm) Weight 2035kg 二、165T-5 Performance Data 三、National PUMP
一、200T-5 PUMP Rated bhp at 400 rpm 200HP(149.1KW) Stroke 5″ (127 mm ) Maximum working pressure “L” MODEL 1680PSI （11583KPA）“M” MODEL 3350PSI ( 23097KPA )“H” MODEL 5000PSI ( 34474KPA ) Max. plunger 4 ″（102mm） Key 7/8”* 7/16”22.2mm x 11.1mm Weight 2035kg 二、200T-5 Performance Data 三、National PUMP
一、200T-5 PUMP Rated bhp at 400 rpm 250HP(187KW) Stroke 5″ (127 mm ) Maximum working pressure “L” MODEL 1680PSI“M” MODEL 3350PSI“H” MODEL 5000PSI Max. plunger 4-1/2 ″ Key 7/8”* 7/16”22.2mm x 11.1mm Weight 2035kg 二、200T-5 Performance Data 三、National 柱塞泵相关泵型
一、JWS185 PUMP Rated bhp at 450 rpm 185HP （137.9KW） Stroke 5“ （127mm） Structure 活塞泵/柱塞泵 Maximum working pressure 10000PSI Max. plunger 4“（101.6mm） Max. piston 4-1/2“（114.3mm） 二、JWS185 Performance Data 三、NATIONAL PUMP
一、JWS340 PUMP Rated bhp at 450 rpm 340HP （253.5KW） Stroke 5“ （127mm） Structure PISTON / PLUNGER Maximum working pressure 10000PSI Max. plunger 4“（101.6mm） Max. plunger 4-1/2“（114.3mm） 二、JWS340 Performance Data 三、NATIONAL PUMP
