I. Features of F1000 MUD PUMP:

  • Having long stroke, being able to operate under low stroke to lengthen the use of expendable parts at the fluid end;
  • Forced lubrication combined with splash lubrication to make lubrication effect;
  • Advanced structure, durable, can ensure itself to operate smoothly, and meet the special requirements of customers to drill medium deep wells;
  • Compact, safe, suction valve and discharge valve are interchangeable, main components of hydraulic cylinder and fluid end on each pump are interchangeable;
  • Durable f luid end great ly improves the performance of triplex mud pump; furthermore,its independent structure makes examination and maintenance convenient.

II. F1000 MUD PUMP Specification

Model

F1600

F1300

F1000

F800

F500

Type

卧式三缸单作用活塞泵

House Power Rating KW/HP

1176/1600

956/1300

735/1000

590/800

370KW(500HP)

Stroke Per Minute

120

140

150

165

Size,Maximum Bore×Stroke

180×305MM (7″×12″)

170×254MM (6-3/4″×10″)

170×229MM (6-3/4″×9″)

170×191MM (6-3/4″×7.5″)

Gear Rating

4.23︰1

4.207︰1

4.185︰1

4.286:1

Suction Inlet

12

12

10

8

Discharge Outlet

5

5

5

4

Pinion Shaft Size

215.9(8- 1/2″)

196.9(7-3/4″)

177.8(7″)

139.7(5-1/2″)

Valve Pots

API-7#

API-6″

API-6″

API-5″

Weight Kg

24143/53226

23924/52743

18790/41425

13000/28660



III. F1000 MUD PUMP Performance Data

Liner Size (mm)

170

160

150

140

130

Pressure Rating
Mpa(kgf/cm2)

16.46
(168)

18.59
(190)

21.18
(216)

24.27
(247)

28.19
(287)

Stroke Per Minute

Horsepower
Rating MPA

VOLUME-Liters Per Second

KW

HP

150

791

1070

43.26

38.30

33.62

29.33

25.25

140

738

1000

40.39

35.76

31.39

27.39

23.58

130

686

929

37.52

33.22

29.16

25.45

21.91

120

646

875

35.34

31.29

27.47

23.97

20.63

110

580

786

31.75

28.11

24.67

21.53

18.53

100

527

714

28.84

25.53

22.41

19.56

16.84

1



0.2884

0.2553

0.2241

0.1956

0.1684

EMSCO F1000 EXPENDABLES PARTS
